− 7 −
bi24d1ea
Travel motion
Key for travel motion in the direction of welding where the symbol is indicated on the
weld equipment. To stop travel motion press , or .
The LED illuminates during travel motion.
Fast motion
Key for fast motion of wire feed or travel motion.
The LED illuminates during fast motion.
Welding start
Key for welding start.
Welding stop
Key for welding stop for all travel motions and all motors.
Positioning knob
The uppermost right−hand knob is called the positioning knob in the instruction
manual and is used to position the cursor.
Settings knob
The three knobs under the panel are called settings knobs in the instruction manual
and are used to change the set values in the panel.
1.2 First step
1.2.1 Choice of language
This menu appears when the machine is first started:
SAW: CA
A 450 Amp
V 30.0 Volt
50 cm/min
|
|
|
|
|
|
NONE NONE
GAS /
FLUX NONE
2ND
FUNCT
The control panel is set to English on delivery. To select your language, proceed as
follows:
GB
