◦ Groove finish
◦ Flat-edge finish
5. Zoom window
Display of the distance from the edges of the lens to the position of the cursor.
6. Position of the center of the groove or bevel
Value expressed in mm ('Front surface tracking' mode) or in % ('Distributed mixed finish' mode).
7. Settings for area 2
◦ Bevel finish
◦ Groove finish
◦ Flat-edge finish
8. Navigation
◦ Stop the cycle
◦ Return to the main edging screen without saving your changes
◦ Start the edging cycle
Area definition screen
1. Lock / unlock the area delimitation points
2. Move the area delimitation points
3. Back to the main screen
