Press and hold with the stylus to set the other points of the step bevel trajectory, one after the other.
With each audible signal, raise the stylus a few seconds before setting a new point by pressing and
holding
It is preferable to create a greater number of points at the angles to gain precision, if you wish to
adjust more precisely the bevel trajectory using the zoom.
Conversely, for easier handling, it is preferable to reduce the number of points on the curves so
the adjustment is more effective.
The step bevel trajectory is set.
The orange trajectory () cannot be performed, because the tool cannot reach it.
The trajectory in green ( ) will be performed (it is not necessary to modify the trajectory).
For more information, consult the Set step bevel section > Adjust the trajectory (F p.91)
Go into zoom mode
You can zoom in on a specific point or outline an area.
