Essilor Pro-E 700 edger User Manual

Press to select the point from which you wish to modify the shape
Press to select the “angle” tool
: Reference point: point from which the shape modification will be started.
: Check-points: points allowing you to modify the curve.
Modify the shape to ensure optimal mounting in the Half Jacket frame.
Press to check the shape’s feasibility.
The button becomes red .
The following screen will appear: The shape is valid.
>
3
4
5
6
Pro-E 600_Pro-E 700 > v1 -10.18
98
USER MANUAL> II. EDGING A LENS
