Getting Started 31
4.2 Wiring
The ports of the ES511.1 may be wired in any order.
The connecting cable for the power supply is part of the delivery scope. The
cables for connecting the modules with each other and for connecting the
host PC must be ordered separately. For order information on other cables
which can be supplied separately, refer to the chapter "Accessoires"
on page 51.
4.2.1 “HOST” Port
To connect the ES511.1 module with the PC (“HOST” port), you require the
CBE500-3 cable or an Ethernet patch cable (see section 3.3 on page 21).
To connect the ES511.1 with the PC
• Connect the HOST port of the ES511.1 with
the PC interface cable CBE500-2
or
• Connect the HOST port of the ES511.1 with
an Ethernet patch cable.
• Connect the cable’s RJ-45 connector with the
free Ethernet interface of your PC.
4.2.2 “6-32V” Port
To connect the ES511.1 Network Module with the power supply, you require
the CBP510-2 cable provided.
To connect the ES511.1 with the power supply
• Connect the CBP510-2 power supply cable
supplied with the 6-32V port of the ES511.1.
Note
Be sure to check that the ports carry no voltage, before starting the cabling.
Note
Make sure you carefully check the names of the cables used. Using the
wrong cables can keep your ES511.1 from functioning properly or damage
the ES511.1 and any devices connected to it.
