Cable and Accessories 49
6.3 CAN-/ LIN-/ FlexRay Cable
Fig. 6-4 CBH500-2 Cable
6.3.1 CAN Terminating Resistor
Fig. 6-5 CBCX131-0 Terminating Resistor
Product Length Order Number
CBH500-2 2 m F 00K 106 276
Product Length Order Number
CBCX131.1-0 - F 00K 103 786
CBH500-2
F 00 K 10 6 2 76
CA N/ LI N /F LX
0000
FM H1
5
4
3
2
1
6
7
8
9
5
4
3
2
1
9
8
7
6
120 Ohm
