4.3 Configuring the ES511.1
The ES511.1 is configured at the PC via a graphic user interface. A web
browser application is used as an interface.
4.3.1 Web Interface
The web interface of the ES511.1 consists of a home page, a page for custom-
ized configuration of the "HOST" interface for the "Auto / On Switch" func-
tion and other pages with information on the status of the ES511.1.
4.3.2 Launching the ES511.1 Web Interface
To launch the ES511.1 web interface:
• Connect the ES511.1 to the PC.
• Start the HSP program on the PC.
•Click Hardware Search.
• Highlight the ES511.1 to be configured in the
“Hardware” window.
• Right-click System Configuration.
The default web browser launches the web
interface for configuring the ES511.1 with the
current IP address of the module in the
address field.
The home page of the ES511.1 web interface
is displayed.
4.3.3 Configuring the “Auto / On Switch” Function
To configure the “Auto / On Switch” function:
•Click Hardware Configuration.
The page for configuring the “Auto / On
Switch” function is displayed.
• Choose Auto and click Save config.
The link signal detector is activated.
or
• Choose On and click Save config.
