ETAS ES511.1 - Interface CAN 1; Interface CAN 2

Technical Data 45
5.4.6 Interface „CAN 1“
5.4.7 Interface „CAN 2“
Pin Signal Meaning
1 n.c. Reserved
2 CAN 1_L CAN LOW
3 CAN 1_UBatt- CAN GND
4 n.c. Reserved
5 CAN 1_Shield Cable shield
6 n.c. Reserved
7 CAN 1_H CAN HIGH
8 n.c. Reserved
9 CAN 1_UBatt+ CAN UBATT
Pin Signal Meaning
1 n.c. Reserved
2 CAN 2_L CAN LOW
3 CAN 2_UBatt- CAN GND
4 n.c. Reserved
5 CAN 2_Shield Cable shield
6 n.c. Reserved
7 CAN 2_H CAN HIGH
8 n.c. Reserved
9 CAN 2_UBatt+ CAN UBATT
