ETAS ES511.1 - Interface ETH2; Interface ETH3

Techni c a l Data44
5.4.4 Interface „ETH2“
5.4.5 Interface „ETH3“
Pin Signal Meaning
1 ETH3_TX+ Received data, plus
2 ETH3_TX- Received data, minus
3 ETH3_RX+ Send data, plus
4 n.c. Reserved
5 n.c. Reserved
6 ETH3_RX- Send data, minus
7 n.c. Reserved
8 n.c. Reserved
G ETH3_GND Ground, interface „ETH2“
Pin Signal Meaning
1 ETH4_TX+ Received data, plus
2 ETH4_TX- Received data, minus
3 ETH4_RX+ Send data, plus
4 n.c. Reserved
5 n.c. Reserved
6 ETH4_RX- Send data, minus
7 n.c. Reserved
8 n.c. Reserved
G ETH4_GND Ground, interface „ETH3“
