Getting Started32
• Connect the supply voltage pins of the cable
with the required power supply.
Note the color coding of the connectors.
Note the current consumption of the ES511.1
and its supply voltage range. The admissible
values are listed in section 5.3.2 on page 40.
4.2.3 “ETH1”, “ETH2”, “ETH3” Port
To connect the ES511.1 module with other modules (“ETH1”, “ETH2” and
“ETH3” port), you require the CBE530-x cable or an Ethernet patch cable (see
section 3.3 on page 21).
Simple Module Network
A simple module network consists of a single ES511.1 module with connected
measure modules. ES51x measure modules are used in the following example.
To connect an ES511.1 with ES51x measure modules
• Connect the ETH1 port of the ES511.1 with
the Ethernet cable CBE530-x
or
• Connect the ETH1 port of the ES511.1 with
an Ethernet patch cable.
• Connect the second cable connector with the
HOST port of an ES51x measure module.
• Connect further modules in accordance with
this principle with the ETH2 and ETH3 ports
of the ES511.1.
Complex Module Network
A complex module network consists of several cascaded ES51x line modules
with connected measure modules. ES51x measure modules are used in the
following example.
