ETAS ES511.1 - CAN Interfaces (CAN 1 and CAN 2); LIN Interfaces (LIN 1 and LIN 2)

Technical Data 41
5.3.4 CAN Interfaces ("CAN 1" and "CAN 2")
5.3.5 LIN Interfaces ("LIN 1" and "LIN 2")
CAN 1 and CAN 2 2 independent interfaces,
galvanically isolated from each other and
from the other interfaces
Protocols CAN V2.0a (Standard Identifier),
CAN V2.0b (Extended Identifier)
Controller IP-Core (FPGA)
Transceiver (Physical Layer) TJA1040
Transfer speed Max. 1 MBaud with a bus length of
20 m
LIN 1 and LIN 2 2 independent interfaces,
galvanically isolated from each other and
from the other interfaces
Specification LIN V2.1
Controller IP-Core (FPGA)
Transceiver (Physical Layer) MCZ33661EF
Operating mode Slave (Monitoring)
