ETAS ES511.1 - Interface LIN 1; Interface LIN 2

Techni c a l Data46
5.4.8 Interface „LIN 1“
5.4.9 Interface „LIN 2“
Pin Signal Meaning
1 n.c. Reserved
2 n.c. Reserved
3 LIN 1_UBatt- LIN GND
4 n.c. Reserved
5 LIN 1_Shield Cable shield
6 n.c. Reserved
7 LIN 1 LIN
8 n.c. Reserved
9 LIN 1_UBatt+ LIN UBATT
Pin Signal Meaning
1 n.c. Reserved
2 n.c. Reserved
3 LIN 2_UBatt- LIN GND
4 n.c. Reserved
5 LIN 2_Shield Cable shield
6 n.c. Reserved
7 LIN 2 LIN
8 n.c. Reserved
9 LIN 2_UBatt+ LIN UBATT
