ETAS ES511.1 - Interface HOST; Interface ETH1

Technical Data 43
5.4.2 Interface „HOST“
5.4.3 Interface „ETH1“
Pin Signal Meaning
1 ETH1_RX+ Received data, plus
2 ETH1_RX- Received data, minus
3 ETH1_TX+ Send data, plus
4 n.c. Reserved
5 n.c. Reserved
6 ETH1_TX- Send data, minus
7 n.c. Reserved
8 n.c. Reserved
G ETH1_GND Ground, interface „HOST“
Pin Signal Meaning
1 ETH2_TX+ Received data, plus
2 ETH2_TX- Received data, minus
3 ETH2_RX+ Send data, plus
4 n.c. Reserved
5 n.c. Reserved
6 ETH2_RX- Send data, minus
7 n.c. Reserved
8 n.c. Reserved
G ETH2_GND Ground, interface „ETH1“
