EQT Router User Manual
Page 34 Revision 1.9.1
Set Level Number
Sets the level number for the device (Currently Only Level 1 is
supported).
Set Xpt Restore at Bootup Sets the XPT to be restore at the bootup.
4.2.10. Viewing / Setting the Clean Switch Configuration (-CS Version Only)
The View / Set Video Signal Configuration menus are used to view and set parameters associated with
the video signals. The following chart provides a brief description of the items available in the View / Set
Video Signal Configuration menu.
View Clean Switch
Configuration
Displays clean switch status, relay status and companion IP address.
View Clean Switch/Relay
Capability
Displays clean switch capability.
Enable/Disable Clean
Switching for Outputs
Sets the state of the clean/quiet outputs, whether they
bypassed (-CS version only).
Enable/Disable Relays
Sets the state of the relays, whether they are enabled or disabled
(EQT-3224 and –CS versions).
Set Companion IP
Address
Sets the IP address of the clean/quiet switch module.
Note: In EQT-3204 the Companion 1 IP address is the IP address of ACO2 Slot 1
and the Companion 2 IP address is the IP address of ACO2 Slot 2.
In EQT-1602 there is only one ACO2 and its IP address will the companion IP
address of EQT-1602.
4.2.11. Viewing / Setting the Video Signal Configuration
The View / Set Video Signal Configuration menus are used to view and set parameters associated with
the video signals. The following chart provides a brief description of the items available in the View / Set
Video Signal Configuration menu.
View Video Signal
Configuration
Displays input video standard and output cable driver and reclocker
status.
Set Video Input Standard Sets the input video standard of the device.
Set Cable Driver Slew
Rate Control
Sets the state of Cable Driver Slew Rate to be Automatic or Manual.
Set Cable Driver Slew
Rate
Sets the Cable Driver Slew Rate to be HD or SD only when the Cable
Driver Slew Rate control is set to Manual.
