DMTA-20102-01EN, Rev. 7, October 2022
Chapter 230
2.6.2 Acquisition Indicator Light
The acquisition indicator light is located on the Pause key (). The color of this light
indicates the operating mode of the OmniScan X3 flaw detector (Table 3 on page 30).
2.6.3 Alarm Indicator Lights
There are three alarm indicator lights located on the upper-right corner of the
OmniScan X3. These lights only flash one color (red) and indicate the trigger status of
their respective alarms (set within the software).
For more details about how to set the alarms that can trigger the alarm indicator
lights, refer to the OmniScan MXU Software User’s Manual.
Orange The OmniScan X3 is turned off. The battery charging is
complete.
Green • The OmniScan X3 is turned on.
• The OmniScan X3 is turned on and the battery is
charging.
Flashing red A critical factor (excessive temperature, very weak battery,
etc.) requires immediate attention.
Table 3 Acquisition indicator light statuses
Off Inspection mode
Orange Analysis mode
Table 2 Power indicator light statuses (continued)
Indicator light Status
