DMTA-20102-01EN, Rev. 7, October 2022
Specifications 63
5.2 Acquisition Connector Specifications
• To reduce the risk of electric shock, avoid touching the inner conductor of the
LEMO connectors. Up to 350 V can be present on the inner conductor of the UT
connectors, and up to 120 V can be present on the PA connector. The warning
symbols near the LEMO connectors signals this electric shock risk (Figure 5-1 on
page 64).
• Reinforced insulation must be provided for the probes connected to the
instrument.
Maximum data file size 25 GB
Onboard storage SSD drive, 64 GB total (OmniScan X3) or 1 TB total
(OmniScan X3 64)
I/O ports
USB ports Two USB 2.0 ports (one hidden behind battery)
One USB 3.0 port
Video output Video out (HDMI)
Memory card SDHC port
Communication Ethernet
I/O lines
Encoder inputs 2-axis currently supported (quadrature or clock/direction)
Third encoder capable (future expansion)
Digital input 6 digital inputs, TTL
Digital output 5 digital outputs, TTL
Acquisition on/off switch Through configuration of a digital input
Power output 5 V nominal, 1 A (short-circuit protected) and
12 V output at 1 A (short-circuit protected)
Table 5 OmniScan X3 general specifications (continued)
