DMTA-20102-01EN, Rev. 7, October 2022
Overview 35
Figure 2-6 LEMO and phased array probe connectors
2.10 Rear Panel
The rear panel incorporates the heat sink with cooling fan and the support stand
(Figure 2-7 on page 36).
To avoid the risk of equipment malfunction or damage from overheating, never
obstruct the free movement of air in the area around the heat sink and cooling fan. Do
not cover the rear of the OmniScan X3 flaw detector with any object or place it against
a surface, which could reduce the movement of air over the heat sink or block the
cooling fan.
Conventional PA connector
LEMO connector
Latching PA connector
