Specifications 67
5.2.3 Data Specifications
This section details the data specifications of processing, TCG, and TFM/FMC (Table 9
on page 67).
Maximum pulsing rate Up to 20 kHz
Display
Refresh rate A-scan: 60 Hz; S-scan: 20 Hz to 30 Hz
Synchronization
On internal clock 1 Hz to 10 kHz
On encoder On 2 axes: from 1 to 65536 steps
Table 9 Data specifications
Processing
Maximum number of A-
scan data points
Up to 16384
Real-time averaging PA: 2, 4, 8, 16
UT: 2, 4, 8, 16, 32, 64
Rectification RF, full wave, half wave+, half wave −
Filtering PA channel (OmniScan X3): 8 low-pass, 6 band-pass, and
4high-pass filters
PA channel (OmniScan X3 64): 9 band-pass and
7 high-pass filters
UT channel: 8low-pass, 6band-pass, and 4high-
pass filters (3 additional filters when configured in
TOFD)
Video filtering Smoothing (adjusted to the probe frequency range)
Programmable TCG
Number of points 32: one TCG (time-corrected gain) curve per focal law
Range PA: 40 dB per step of 0.1 dB
UT: 100 dB per step of 0.1 dB
Maximum slope PA: 40 dB/10 ns
UT: 40 dB/10 ns
TFM/FMC
