DMTA-20102-01EN, Rev. 7, October 2022

Connector References 71

6.2 Alarm and I/O Connector

Description

LEMO, 14-pin female circular connector

Manufacturer, number

LEMO, HMA.1K.314.CLLP

Suggested cable connector

LEMO, FGA.1K.314.CLAC65Z

9 In PhA1 Encoder 1 / Phase A_CLK N/A TTL

10 In PhB1 Encoder 1 / Phase B_DIR N/A TTL

11 In PhB2 Encoder 2 / Phase B_DIR N/A TTL

12 In PhA2 Encoder 2 / Phase A_CLK N/A TTL

13 Out DOUT3 Digital output 3 ±20 mA TTL

14 In DIN5 / PhA3 Digital input 5 / Encoder 3 /

Phase A_CLK

N/A TTL

15 In DIN6 / PhB3 Digital input 6 / Encoder 3 /

Phase B_DIR

N/A TTL

16 – GND Ground N/A N/A

a. NC = Not connected.

b. Shared with Alarm and I/O connector.

Table 10 Pinout for the scanner encoder LEMO connector (continued)

Pin I/O Signal Description Current Level
