for this protocol there are no congurable parameters:
data transmission
This function allows you to select which communica-
tion interface to use for data transmission. The available
interfaces are:
- “Serial RS232” and “IrDA kit”: for the communication
with serial or infrared data acquisition devices.
- “Always EVA DTS” for communications with data acqui-
sition and transmission devices (telemetry)
type
Select which communication speed
to use between:
- “ENHANCED”, the communication speed is automati-
cally adjusted to the speed of the slowest device
- “STANDARD 9600”: the communication speed is xed
at 9600 bps
transmission speed
Allows to select the transmission communication speed.
Default setting 2400 bps.
ConneCtion
By activating this function, the machine waits for the con-
nection with a data acquisition device EVA DTS.
statistiCs reset
The statistics can be reset, for the relative counters, in a
global mode (all types of data) or in a selective mode
By pressing the conrmation key

the ashing conr-
mation request “Conrm?” is displayed.
By pressing the conrmation key

the message “Ex-
ecution” is displayed for a few seconds and the statistics
are reset.
display of relative statistiCs
By pressing the conrmation key

the stored data is
displayed in sequence:
1 - single selection counter;
2 - bands counter;
3 - discounts counter;
4 - faults counter;
5 - Coin box data.
relative statistiCs reset
The statistics can be reset, for the relative counters, in
a global mode (all types of data) or in a selective mode,
for:
- selections
- discounts-overpays
- faults
- coin box data
By pressing the conrmation key

the ashing conr-
mation request “Conrm?” is displayed.
By pressing the conrmation key

the message “Ex-
ecution” is displayed for a few seconds and the statistics
are reset.
bdv protoCol audit
The coin mechanism data are intended to supply the fol-
lowing information in real currency:
- Aud.1 Money in the tubes
Money currently available in the change tubes
- Aud 2 Money to the tubes
Money conveyed to the change tubes
- Aud 3 Money to the coin box
Money conveyed to the coin box
- Aud 4 Change returned
Total amount of the money that has been returned
- Aud 5 Money dispensed:
Total amount of the money that has been manually
dispensed
- Aud 6 Surplus
Surplus money. Amounts paid by the customer in
excess and not returned (in case no money is available
for change)
- Aud 7 Total sales
Total sales value
- Aud 8 Exact change
Sales value on the “Insert exact amount” condition
- Aud 9 Mixed dispensing
Total dispensing value paid in a dierent way, e.g. also
other types of payment (C.P.C., coin)
- Aud 10 Manual load
Money inserted into the coin mechanism by means of
the manual loading function
