mdb protoCol audit
- Aud.1 Money in the tubes
Money currently available in the change tubes
- Aud 2 Money to the tubes
Money conveyed to the change tubes
- Aud 3 Money to the coin box
Money conveyed to the coin box
- Aud 4 Change returned
Total amount of the money that has been returned
- Aud 5 Surplus
Surplus money. Amounts paid by the customer in
excess and not returned (in case no money is available
for change)
- Aud 6 Unloading of tubes
Value of the coins dispensed by means of the “Manage
tubes” function
- Aud 7 Loading of tubes
Value of the coins cashed by means of the manual
loading function.
- Aud 8 Cash sales
Value of the total sales made cash (coins + bills)
- Aud 9 Bills cashed
Value of the bills that have been cashed
- Aud 10 Charge key
Value of the money that has been recharged on the key
- Aud 11 Key sale
Value of the money that has been cashed through key-
dispensing
- Aud 12 Money dispensed manually
Value of the coins that have been manually dispensed
through the dispensing buttons on the coin mechanism.
printing
By connecting an RS232 serial printer with a baud rate
of 9600, 8 data bits, parity of None and 1 stop bit to the
serial connector on the button board, it’s possible to print
all the statistics described in the paragraphs “display
general statistics” and “display relative statistics”; the
printout also shows the code of the machine, the date
and the software version.
Printing the statistics can be performed in a relative or
total mode.
To connect the printer follow these steps:
- press the printing confirmation key

and the confirma-
tion request “Confirm?” is displayed;
- connect the printer before confirming;
- by pressing the confirmation key

printing will start.
COMMUNICATION
up-key
setup management
upkey -> vending maChine
After having inserted the Up key into the plug on the
C.P.U. board, this function is used to select the setup le
from the list on the display. Press the Enter key to load
the setup le you have selected on the machine.
vending maChine ->upkey
After having inserted the Up key into the plug on the
C.P.U. board, this function is used to save on the Up key
a setup le with the same conguration currently avail-
able on the machine.
Please specify the name you wish to assign to the le
(e.g.: VENDM000.STP)
delete
Use this function to delete one or more than one setup
le on the up key you have inserted
delete all
Use this function to delete all the setup les on the up
key you have inserted.
