3 05 2013 4365 00
POSITIONING OF THE VENDING MACHINE
The machine is not suitable for outside installations, it
needs to be installed inside dry premises away from heat
sources, with temperature between 2° and 32° C and it
cannot be installed in environments in which jets of water
are used for cleaning (i.e.: large kitchens, etc.).
The machine should be positioned next to a wall and in
such a way that the back of it is at a minimum distance
of 4 cm from the wall in order to allow regular ventilation;
the machine should not be covered with cloths or similar.
The machine shall be positioned so that the maximum
inclination does not exceed 2°. If needed, level it out us-
ing the appropriate adjustable feet.
TECHNICAL CHARACTERISTICS
Height mm 1830
Width mm 600
Width with open door mm 1200
Depth mm 740
Depth with open door mm 1250
Weight without packaging Kg 118
Power supply voltage V∿ 230-240
Power supply frequency Hz 50
Absorbed current A 10
Installed power W 2350
600
1200
740
1250
1830
Fig. 2
Cups and stirrers
Diameter of the upper border of 73-74 mm with a capac-
ity of 620 plastic cups or 480 paper cups; about 550
stirrers (where a stirrer dispenser is provided).
noise level
The weighted continuous equivalent sound pressure
level is less than 70 dB.
payment system
The machine is supplied with electrical arrangement
for systems with protocol Executive, BDV, MDB and for
monitoring 24 Vdc validators.
Apart from the coin box housing, there is space for the
optional installation of the most common payment sys-
tems.
selling priCes
A dierent price can be programmed for each selection;
the standard calibration sets the same selling price for all
selections.
Coin box
You can also mount a cover and a lock.
Water supply
With water supply from mains with water pressure be-
tween 0.05 and 0.85 MPa (0.5 and 8.5 bar).
The machine’s software is arranged for controlling the
water supply from an internal tank (optional kit).
possible adjustments
Freshbrew: tea or coee doses, timed water
infusion time and drying time
Instant: Coee doses, timed instant and water .
Temperature: Adjustable via software.
enable signals
- Presence of cups
- Presence of water
- Infuser unit initial position
- Liquid waste container
- The operating temperature is reached
