Design and function
TIG welding
40
099-000121-EW501
29.06.2015
• Keep the "welding parameters" button pressed for 4 s.
NAVIGATION (Navigating in the menu)
• Parameters are selected by pressing the "welding parameters" button.
• Set or change the parameters by turning the "welding parameter setting" rotary dial.
EXIT (leave the menu)
• After 4 s, the machine will return automatically to the ready-to-operate status.
The expert menu includes functions and parameters which are either not set on the machine control, or
which do not require regular setting.
ENTER EXIT
4 s
NAVIGATION
4 s
Figure 5-14
Display
Setting/selection
Expert menu
Slope time tS1 (main current to secondary current)
Setting: 0.00 s to 20.0 s (factory setting 0.00 s)
Slope time tS2 (secondary current to main current)
Setting: 0.00 s to 20.0 s (factory setting 0.00 s)
activArc parameter
Parameter can also be set after activating TIG activArc welding.
Display shown = factory setting.
