EWM Tetrix 300 - Pulses, Function Sequences; TIG Pulses - Non-Latched Operation; TIG Pulses - Latched Operation

Design and function
TIG welding
50
099-000121-EW501
29.06.2015
5.9.12 Pulses, function sequences
The function sequences in pulses basically behave in the same way as in standard welding, but
during the main current phase there is a continual switching back and forth between the pulse
and pause currents at the relevant times.
The pulse function can also be deactivated if necessary during the upslope and downslope
phases- See 5.18 Machine configuration menu chapter.
5.9.12.1 TIG pulses – non-latched operation
Figure 5-23
5.9.12.2 TIG pulses - latched operation
Figure 5-24
