MS Series PABX User Manual
44
I.2 Set Door-phone function
You need to perform the following setting in system programming status by
programming extension(Ext.601-604)
I.2.1Set the portof Door phone
Format: 80N# set the first door phone (N is Ext port number)
81N# set the second door phone (N is Ext port number)
8000# clear setting of the first door phone
8100# clear setting of the second door phone
Default: door phone is not set
I.2.2 Door phone ringingExtensionSetting
Format: 8 2 #
Description: Clear all extension assigned to door phone.
Format: 8 2 N#
Description: Set Ext.N as the ringing extension when door phone call in
NOTE: ◆ On default setting: Ext.601 & Ext.602 are ringing extension for
door phone call.
◆ Maximum 8 extensions can be set as the ringing extension for
door phone call.
I.2.3 Set Duration of switch Signal
Format : 1 8 5 TT#
Explanation: TT = 01-99 opener action time is TT*0.1s
Description: Set the door opener action time (the closing time for the relay
of door opener).
Description:If you press * 1 to open the door, the unlock signal will be kept
in a few seconds. You can set the duration of unlock signal to match with
electric lock.
On default setting, TT=4, means 0.4s.
I.3 Operating Instruction
Operation1: Press the call button on door phone and press*1 to open the
door lock.
Description: when visitor press the call button on door-phone,The door
phone ringing extension will ring, at this moment the door phone will be on
the status of music on hold (if nobody answer after 25s, system will send a
busy tone to door phone),you pick up the ringing extension to talk with the
visitor.
During talking with the door phone caller, Extension input *1 to open the
door lock.
● Any extension can pick up the call and open the door when
visitor press door phone
