Inspecting Fiber Ends
68 FIP-400B
Inspecting Multiple Fiber Ends (MF-Ready Probes Only)
8. To specify the connector subtype, proceed as follows:
8a. Tap at the end of the Connector Subtype row.
8b. Select a connector subtype.
8c. Tap to return to the Analysis Configuration window.
9. To indicate if you have inserted the removable nozzle key up or key
down, proceed as follows:
9a. Tap at the end of the Connector Key Orientation row.
