FTB-500 135
7 Inspecting Fibers with a Probe
The fiber inspection probe (FIP) is used to find dirty or damaged
connectors by displaying an enlarged view of the connector surface. You
can connect a probe to your unit to view fiber ends.
Fiber inspections are made using the ConnectorMax2 application. For
more information, refer to the ConnectorMax2 online help.
To inspect fibers with a probe:
1. Connect the probe to your unit.
IMPORTANT
Only the probes of the FIP-400B series are supported on your unit.
IMPORTANT
Make sure that you connect the probe to the USB port that is
closest to the bottom, on the front panel of the unit. Otherwise, the
probe will not be detected properly.
