Preparing for Automation

192 FTB-500

Linking Units with the Serial Port

Linking Units with the Serial Port

Your unit is equipped with a serial (RS-232) port to send and receive data.

Refer to the Microsoft Windows documentation for information about

serial port settings and possibilities.

Serial port
