Preparing for Automation

FTB-500 191

Linking Units with the Ethernet Port

Linking Units with the Ethernet Port

Your unit is equipped with an Ethernet port (10/100/1000) to send and

receive data. Refer to the Windows documentation for information about

Ethernet port settings and possibilities.

Ethernet port
