Maintenance

FTB-500 269

Replacing Batteries

4. Repeat steps 2 and 3 with the other battery (two remaining batteries

for the eight-slot model).

5. Close the battery compartment and tighten the retaining screw back

into position (two retaining screws on the eight-slot model).

Eight-slot model

Battery poles
