Extra EA 400 - Page 239

Pilot’s Operating Handbook Section 6
EXTRA 500 Weight and Balance and Equipment List
Weight and Moment Table (SI units)
Fuel main & collector compartment (max. 440 liters usable)
Quantity
(1)
Weight
(kg)
Arm
(m)
Moment
(kgm)
20 16,3 3,768 61
40 32,6 3,768 123
60 48,8 3,768 184
80 65,1 3,768 245
100 81,4 3,768 307
120 97,7 3,768 368
140 114,0 3,768 429
160 130,2 3,768 491
180 146,5 3,768 552
200 162,8 3,768 613
220 179,1 3,768 675
240 195,4 3,768 736
260 211,6 3,768 797
280 227,9 3,768 859
300 244,2 3,768 920
320 260,5 3,768 981
340 276,8 3,768 1043
360 293,0 3,768 1104
380 309,3 3,768 1166
400 325,6 3,768 1227
420 341,9 3,768 1288
440 358,2 3,768 1350
Figure 6-6 a
Weight and Moment Table / Fuel (Sheet 1 of 2)
04. May 2004 6-17
