Section 6 Pilot’s Operating Handbook
Weight and Balance and Equipment List EXTRA 500
Weight and Moment Table (U.S. units)
Fuel main & collector compartment (max. 114 gal usable)
Quantity
(U.S. Gallons)
Weight
(lbs.)
Arm
(in.)
Moment
(in.lbs./100)
5 35 148 51
10 70 148 103
15 104 148 154
20 139 148 206
25 174 148 257
30 209 148 309
35 243 148 360
40 278 148 411
45 313 148 463
50 348 148 514
55 382 148 566
60 417 148 617
65 452 148 669
70 487 148 720
75 521 148 771
80 556 148 823
85 591 148 874
90 626 148 926
95 660 148 977
100 695 148 1029
105 730 148 1080
110 765 148 1131
114 790 148 1169
Figure 6-6 a
Weight and Moment Table / Fuel (Sheet 2 of 2)
6-18 26. January 2011
