Pilot’s Operating Handbook Section 6
EXTRA 500 Weight and Balance and Equipment List
Weight and Moment Table (SI units)
Fuel auxiliary compartment (max. 212 liters usable)
Quantity
(1)
Weight
(kg)
Arm
(m)
Moment
(kgm)
20 16,3 3,9 63
40 32,6 3,9 127
60 48,8 3,9 190
80 65,1 3,9 254
100 81,4 3,9 317
120 97,7 3,9 381
140 114,0 3,9 444
160 130,2 3,9 508
180 146,5 3,9 571
200 162,8 3,9 635
212 172,6 3,9 673
Figure 6-6 b
Weight and Moment Table / Fuel (Sheet 1 of 2)
26. January 2011 6-19
