Extra EA 400 - Page 242

Section 6 Pilot’s Operating Handbook
Weight and Balance and Equipment List EXTRA 500
Weight and Moment Table (U.S. units)
Fuel auxiliary compartment (max. 55 gal usable)
Quantity
(U.S. Gallons)
Weight
(lbs.)
Arm
(in.)
Moment
(in.lbs./100)
5 35 154 54
10 70 154 107
15 104 154 161
20 139 154 214
25 174 154 268
30 209 154 321
35 243 154 375
40 278 154 428
45 313 154 482
50 348 154 535
55 382 154 589
Figure 6-6 b
Weight and Moment Table / Fuel (Sheet 2 of 2)
6-20 26. January 2011
