Section 2 Pilot’s Operating Handbook
Limitations EXTRA 500
Next to each fuel tank drain (8x), sump drain on the lower side
of the wing (2x) and near the lower fuel overboard drain line
(1x; bottom side of the fuselage, aft of the nose gear bay):
FUEL DRAIN
Next to the fuel filter drain (aft of cowling bottom part):
FUEL FILTER DRAIN
Outside/inside the oil access panel (right top of the engine
cowling):
OIL
On the right keel beam next to the refill opening of the
reservoir:
HYDRAULIC FLUID
MIL-H-5606G and
MIL-PRF-5606H or later
