Pilot’s Operating Handbook Section 2
EXTRA 500 Limitations
On the brake fluid reservoir positioned at the firewall:
BRAKE FLUID
MIL-H-5606G and
MIL-PRF-5606H or later
External power access panel (above the oil cooler air outlet,
right fuselage side):
Near the external oil filter indicator (opening in the RH lower
part of the cowling):
OIL FILTER
BYPASS INDICATOR BUTTON
On the main landing gear oleo shock absorber (LH & RH):
HYDRAULIC FLUID
MIL-H-5606G and
MIL-PRF-5606H or later
57 bar (827 PSI)
On the nose landing gear strut (oleo shock absorber):
HYDRAULIC FLUID
MIL-H-5606G and
MIL-PRF-5606H or later
15 bar (218 PSI)
26. January 2011
2-41
