4. Remove the fan assembly from the anti-static shielded bag.
Note
Do not force the installation. If the fan assembly does not slide in easily, ensure that it is
correctly oriented before continuing.
5. Holding the fan assembly level, guide it into the carrier rails on each side and gently push it all the
way into the slot, ensuring that it firmly engages with the connector.
6. When you are sure the fan assembly has properly engaged the connector, tighten the captive screw
to secure the fan assembly in the slot.
Note
The fans are controlled automatically by the device.
When a fan assembly is installed in a slot, the power LED on the fan assembly should turn on green to
confirm that the fan assembly is correctly installed and running. Refer to “LED activity interpretation” on
page 45.
Caution
If you do not install a module or a power supply in a slot, you must keep the slot filler panel in
place. If you run the chassis with an uncovered slot, the system will overheat.
Inserting a new fan assembly Fan Assemblies
92 ExtremeRouting SLX 9640 Hardware Installation Guide
