4. Screw, 8-32 x 5/16-in., panhead Phillips (8)
5. Screw, 8-32 x 5/16-in., flathead Phillips (16)
6. Screw, 6-32 x 1/4-in., panhead Phillips (8)
7. Screw, 10-32 x 5/8-in., panhead Phillips (8)
8. Retainer nut, 10-32 (8)
Ensure that the items listed and illustrated in Figure are included in the kit. Note that not all parts may
be used with certain installations depending on the device type.
Caution
Use the screws specified in the procedure. Using longer screws can damage the device.
Flush-front mounting
Observe the following notes when using this procedure:
• The device must be turned o and disconnected from the fabric during this procedure.
• The illustrations in this document show a 1U device, but the instructions are the same for a 2U device.
• The illustrations for this procedure show a two-post rack with narrow posts (3- to 5-inch) as an
example.
• The illustrations in the rack installation procedures are for reference only and may not show the
actual device.
Caution
Use the screws specified in the procedure. Using longer screws can damage the device.
Complete the following tasks to install the device in a rack:
1. Attaching the front brackets to the device on page 30
2. Attaching the front brackets to the rack on page 31
3. Attaching the rear brackets to the rack on page 32
4. Attaching the rear brackets to the device on page 33
Attaching the front brackets to the device
Complete the following steps to attach the front brackets to the device.
1. Position the right front bracket with the flat side against the right side of the device, as shown in
Figure 10.
2. Insert four 8-32 x 5/16-in. flathead screws through the vertically aligned holes in the bracket and
then into the holes on the side of the device. Use the upper and lower screw holes, leaving the center
holes empty.
3. Repeat step 1 and step 2 to attach the left front bracket to the left side of the device.
Flush-front mounting
Mounting the Device
30 ExtremeRouting SLX 9640 Hardware Installation Guide
To Next Page
