Installation requirements
Provide space in an EIA rack with the following minimum and maximum distances between the front
and back posts.
Note
For 1U and 2U devices, two people are required to install the device in a rack. One person
holds the device, while the other screws in the front and rear "L" brackets.
Table 14: Space requirements
Chassis with port-side side
vents
Notes Chassis
depth
Minimum
rack depth
Maximum
rack depth
No Applicable to
port-side and
nonport-side
flush mounts.
L L-12.7 cm
(L-5 in.)
81.28 cm (32
in.)
Yes Applicable to
port-side
flush mounts.
L L-12.7 cm
(L-5 in.)
81.28 cm (32
in.)
Yes Applicable to
nonport-side
flush mounts.
L L 81.28 cm (32
in.)
Note that if chassis depth (L) is less than 40.64 cm (16 in.), the chassis will not fit into a rack with a
maximum depth of 81.28 cm (32 in.) using the universal four-post rack kit. The maximum rack depth for
a chassis less than 40.64 cm (16 in.) is 81.28 cm (32 in.) minus the dierence between the chassis depth
and 40.64 cm (16 in.). For example, a chassis with a depth (L) of 35.56 cm (14 in.) is 5.08 cm (2 in.)
smaller than 40.64 cm (16 in.), so it will install into a rack with a maximum depth of 81.28 cm (32 in.) -
5.08 cm (2 in.) = 76.2 cm (30 in.).
Review the installation and facility requirements for your product before mounting the device . Refer to
the Hardware Installation Guide for your product for more information.
Time and items required
Allow 15 to 30 minutes to complete the installation.
The following items are required to install the device using the Universal Four-Post Rack Kit:
• #2 Phillips torque screwdriver
• 1/4-inch slotted-blade torque screwdriver
Parts list
The following parts are provided with the Universal Four-Post Rack Kit (XEN-R000296).
Installation requirements
Mounting the Device
40 ExtremeRouting SLX 9640 Hardware Installation Guide
