LEDs
System component Description
Interface Port LEDs • Solid O: No Link
• Solid ON: Link, no trac
• LED Flickering: Link, trac activities
Power supply LEDs • O: No Power (no lights).
• Green: Steady: Power GOOD - Main output and standby output enabled
with no power supply warning or fault detected.
• Amber Blinking: Warning - Power supply warning detected.
• Amber Steady: FAULT - Power supply fault detected.
Fan module LEDs • Power (Fan) LED: No light (LED is o) - Fan assembly does not have
power. Green Steady - Fan Normal.
• Status (Fan) LED: No light (LED is o) - Fan assembly is either healthy or
does not have power. Amber Steady - Fan assembly is being initialized or
has a failure (full or partial).
Other
System component Description
Serial Cable RJ-45 console cable
RJ-45 to DB9 adapter 1 (RJ-45 port to female DB9 connector)
AC power cord, power
clip
For both units
Weight and physical dimensions
The SLX 9640 Switch Router is 1 RU and 16" in depth.
Model Dimensions (with Fan FRU) Weight (with 6 x Fan FRUs and 2
x PSUs without optics)
SLX 9640 Router 445 x 43.7 x 451.5 mm 8.96 Kg (19.712 lbs)
Fan tray 42.0 x 41.2 x 94.6 mm 0.18 Kg (.396 lb.)
Power Supply Unit 54.4 x 40.0 x 236.6 mm 0.76 Kg (1.672 lbs)
Environmental requirements
Condition Operational Non-operational
Ambient
temperature
0°C to 40°C (32°F to 104°F) (F2B)
-5°C to 50°C (23°F to 122°F) (F2B) with
6 fan assemblies
-40°C to 70°C (-40°F to 158°F)
Relative humidity
(non-condensing)
5% to 95% at 50°C (122°F) 5% to 95% at 70°C (158°F)
LEDs ExtremeRouting SLX 9640 Technical Specifications
94 ExtremeRouting SLX 9640 Hardware Installation Guide
