Extreme Networks ExtremeRouting SLX 9640 User Manual

Power consumption (maximum configuration)
All 100-GbE ports are linked up, loading with 100 percent trac rate. Two power supplies and six fan
assemblies. Fans at high speed.
@100 VAC Input (Input
power ±5%)
@200 VAC Input
(Input power ±5%)
@-48VDC Minimum number
of power supplies
Notes
570 W
1,945 BTU/hr
544.1 W
1,857 BTU/hr
552 W
1,884 BTU/hr
1 x 650 W AC
1 x 650 W DC
1 power supply
581.2 W
1,983 BTU/hr
562.4 W
1,919 BTU/hr
563 W
1,921 BTU/hr
1 x 650 W AC
1 x 650 W DC
2 power supplies
Data port specifications (Ethernet)
System component Description Maximum
ports
supported
QSFP28 ports 100 GbE QSFP28 ports can support 40GE/4x10GE/100GE/
4x25GE/2x50GE interfaces.
12
SFP+ ports The SFP+ ports can support 10GbE/1GbE interfaces. There
are 24 x SFP+ ports.
24
Ethernet management
port
RJ-45 port with 10/100/1000 Mbps auto-negotiating
capability
1
Serial port specifications (pinout RJ-45)
Pin Signal Description
1 Not supported N/A
2 Not supported N/A
3 RXD Receive data
4 GND Logic ground
5 Not supported N/A
6 TXD Transmit data
7 Not supported N/A
8 Not supported N/A
Serial port specifications (pinout - mini-USB)
Pin Signal Description
1 Reserved Not used
2 UART0_RX Debug port (data received by SLX)
3 UART0_TX Console port (data transmitted by
SLX)
Power consumption (maximum configuration) ExtremeRouting SLX 9640 Technical Specifications
96 ExtremeRouting SLX 9640 Hardware Installation Guide
