MLC 62 Series • Hardware Setup
2-3
Button illumination
The front panel button illumination provides you with status on
what the MLC is doing. The buttons are lit while the MLC has
power. When a button has been pressed and is active or on, it
lights brightly. When a button is inactive or off, it is lit dimly.
When buttons are placed in a mode that groups them together
(for example, Input mode) only the button that is pressed lights
brightly. The other buttons in the group remain dim. (Refer to
the configuration software's help file for information on setting
button modes.)
