MLC 62 Series • Hardware Setup
2-9
7
Test the system: press the MLC’s buttons, watch the
display, and listen to the audio output to determine
whether the connected devices are responding correctly
(powering on and off, switching inputs, and so forth). If
not, ensure that all devices are plugged in and receiving
power. Check the cabling and make needed adjustments.
8
Disconnect power from all devices:
• Disconnect the MLC’s power supply at the power
source end (not at the MLC end).
• Disconnect the other devices’ power.
9
Mount the MLC to the mounting surface, following the
procedure appropriate for your MLC model, later in this
chapter:
• For MLC 62 D models, see "Mounting the MLC 62 D".
• For MLC 62 EU models, see "Mounting the
MLC 62 EU".
10
Restore power to the MLC and to the connected devices.
Removing and replacing the faceplate
Each MLC 62 model is delivered with a faceplate attached.
This faceplate can be removed if you want to replace any of the
buttons or exchange the faceplate for another one.
N
The MLC 62 D is delivered with a black faceplate attached.
If you want it to have a white faceplate, you can remove
the black one and replace it with the white one that is also
provided with the product. (A matching Decora wallplate
is also provided for each faceplate.)
Faceplate replacement kits containing six-button or eight-button
faceplates can be ordered. (Refer to appendix A, "Reference
Information", in the MLC 62 User's Manual for information.)
