MLC 62 Series • Hardware Setup
Hardware Setup, cont’d
2-16
C
The power supply shall not be permanently fixed to
the building structure or similar structures.
The power supply shall not be located within
environmental air handling spaces or within the wall
cavity.
The installation shall be in accordance with the
applicable provisions of the National Electrical
Code ANSI/NFPA 70, Article 725 and the
Canadian Electrical Code, Part 1, Section 16.
The power supply is to be located within the same
vicinity as the Extron A/V processing equipment in
an ordinary location, Pollution Degree 2, secured
to the equipment rack within the dedicated closet,
podium or desk.
Mounting the MLC 62
Once the system has been cabled, configured, and tested, the
MLC can be installed in the wall or furniture.
Mounting the MLC 62 D
You can mount the MLC 62 D to a UL-approved electrical
junction box or to a Decora mounting bracket (included). The
procedures are described in the following sections.
Mounting to an electrical junction box
1. Mount the electrical junction box in the wall or furniture,
following the directions provided with the box.
2. Configure the MLC's buttons and switch the faceplate if
desired.
3. Connect all cables to the MLC and disconnect power at the
source.
4. Insert the MLC unit into the mounted electrical junction
box.
5. Secure the MLC to the box using two of the provided
screws in the slots at the top and bottom of the unit.
6. Fasten the Decora wallplate onto the unit using two of the
provided screws in the holes at the top and bottom.
