MLC 62 Series • Hardware Setup
2-19
To mount the MLC 62 EU to a one-gang electrical box:
1. Mount the electrical box in the wall or furniture, following
the directions provided with the box.
2. Configure the MLC's buttons and switch the faceplate if
desired.
3. Attach the provided metal mounting bracket to the
mounted electrical box using two of the included screws in
the slots at the top and bottom of the bracket.
4. Pull the cables through the electrical box and the plastic
wall frame.
5. Connect all cables to the MLC and disconnect power at the
source.
6. Align the wall frame to the metal mounting bracket on the
mounting surface.
6. Holding the wall frame in place on the bracket, press the
MLC into the frame until the unit snaps into place.
Accessing the Front and Side Panels After
Mounting
After the MLC is installed in the mounting surface, you can
still access the covered front and side panel controls using the
following procedures.
Accessing covered MLC 62 D front panel features
After the MLC 62 D has been mounted, the following front panel
items are covered by the wallplate: IR sensor, DIP switches,
Reset button, and USB connector.
To access these controls, unfasten the two screws at the top and
bottom of the wallplate and lift it off the controller. (See the
illustration on the next page.)
