Extron electronics XTP II CrossPoint Series User Manual

Output boards Output endpoints
Command
family
XTP Fiber 4K HDMI
HDMI
DVI Pro Analog
audio
XTP R HDMI
XTP R HWP 101
receivers
XTP SR HDMI
scaler
Advanced IP and
Remote
Port
Audio routing selections N/A N/A Page 102 Page 102 N/A Page 106 Page 108
HDCP status N/A Page 102 Page 102 Page 102 N/A Page 107 Page 108
Captive screw and
Ethernet serial port
insertions
Page 104 Page 104 N/A N/A N/A N/A N/A
Ethernet serial port insert
parameters
Page 104 Page 104 N/A N/A N/A N/A N/A
XTP power Page 105 N/A N/A N/A N/A N/A N/A
Video mutes N/A Page 102 Page 102 Page 102 N/A Page 102 Page 107
Output audio volume N/A N/A Page 103 Page 103 Page 103 Page 106 Page 108
Audio mutes N/A N/A Page 104 Page 104 Page 104 Page 106 Page 108
Relay controls Page 107 Page 109
View video and audio
mutes
N/A Page 104 Page 104 Page 104 Page 104 Page 107 Page 109
Black video resolution
within switcher
Page 110
Video and audio test
patterns
Page 110
Names Page 110
Front panel locks Page 110
Create global presets Page 111
Resets Page 111
View settings Page 112
File directory Page 113
Information requests Page 114
IP and remote port setup Page
117
Table 8. SIS Command vs. Switcher or Board Type Cross-Reference,
Output, Advanced, and IP and Remote Port Commands
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 83
