MCS- 18/92 Digital Brushless AC servo drive system - Ref.0707
Non-ventilated
motors
Stall torque
Stall peak
torque
Rated
speed
Stall current
Peak
current
Rated power
Torque
constant
Acceleration
time
Inductance
per phase
Resistance
per phase
Inertia
1)
Mass
2)
Peak torque
Mo
Nm
Mp
Nm
nN
rev/min
Io
Arms
Imax
Arms
PoW
kW
Kt
Nm/Arms
tac
ms
L
mH
R
Ω
J
kg·cm
2
M
kg
MCS-08H
Nm
MCS-16H
Nm
FKM21.60A.. 1.7 7 6000 2.8 11 1.1 0.6 14.4 7.7 2.6 1.6 4.2 5.0 7.0
FKM22.30A.. 3.2 13 3000 2.4 10 1.0 1.3 7.0 16.0 3.95 2.9 5.3 10.2 13.0
FKM22.50A.. 3.2 13 5000 4.0 16 1.7 0.8 11.7 5.8 1.4 2.9 5.3 6.7 13.0
FKM42.30A.. 6.3 25 3000 4.6 19 2.0 1.4 10.7 8.6 1.45 8.5 7.8 21.9
FKM42.45A.. 6.3 25 4500 6.9 28 3.0 0.9 16.0 3.9 0.675 8.5 7.8 14.6
FKM44.30A.. 11.6 47 3000 8.2 33 3.6 1.4 11.2 4.2 0.54 16.7 11.7 22.6
FKM44.40A.. 11.6 47 4000 10.7 43 4.9 1.1 14.9 2.4 0.315 16.7 11.7 17.3
FKM62.30A.. 8.9 35 3000 7.1 28 2.8 1.3 14.4 7.2 0.77 16.0 11.9 20.0
FKM62.40A.. 8.9 35 4000 9.3 37 3.7 1.0 19.1 4.1 0.44 16.0 11.9 15.4
FKM64.30A.. 16.5 66 3000 12.1 48 5.2 1.4 14.0 3.8 0.285 29.5 17.1 21.8
(1 Motor inertia without brake.
(2 Motor mass without brake.
Note: The drive recommended to govern each motor must supply the rated current needed to obtain the rated torque from the motor.
CHARACTERISTICS TABLE OF NON-VENTILATED FKM MOTORS WITH “A” WINDING (400 V AC)
