MPC-6000 / MPC-7000 / RND-2 PROGRAMMING MANUAL
8
Step Number
Configure Description
4 Devices Set the address and other parameters for each
of the devices that will be installed into the
system. Configure the input group of each
device. Note that devices must be connected to
an input group for any output to be activated. If
the panel is networked, also setup the network
group that this device will activate.
5 Notifications
appliance circuits
Configure the behavior of the NACs and the
output zone that will activate each NAC. Note
that a NAC must be configured as connected to
an output zone or it will not activate.
Optional 6 RDC-2 Annunciators If there are any remote RDC-2 displays, set
whether installed.
Optional 7 Remote LEDs If there are any remote LED modules, configure
each of the remote LEDs. Select the Output
zone that will activate the LED.
Optional 8 Remote Relays If there are any remote Relay modules,
configure each of the remote Relays. Note that
the Relays must be connected to an Output
Zone in order to activate.
Optional 9 DACT line/DACT
account
If a dialer is installed, configure the line and
account data.
Optional 10 Releasing Application If configured in the system parameters,
configure the releasing features parameters.
11 Validate Run validate and fix any errors that are reported.
12 Activate Swap the backup configuration with the primary
configuration.
IMPORTANT NOTE: Special considerations apply to programming an RND-2 panel as
opposed to either an MPC-6000 or MPC-7000 panel. No devices (inputs or outputs), no
NACs, no SLUs nor any SRUs can be connected or programmed. Only the MPC-DACT
DACT board or the CT-1K City Tie board, the RDC-2 Annunciator and the network may
be connected and programmed to an RND-2 panel.
