MPC-6000 / MPC-7000 / RND-2 PROGRAMMING MANUAL
11
The basic concept is that loop devices are configured and grouped into input groups.
The input groups are set to have a certain behavior and activate output zones. The
output devices―whether relay bases, audible bases, NACs, serial LEDs or Serial
relays―are configured and connected to Output Zones.
Automatic Programming
Auto-program can be done with a new, non-configured control unit or to augment an
existing configuration. Augmenting an existing program adds new points but leaves
previously programmed points unaffected. Discrepancies in the configuration will be
presented individually for acceptance. Again, auto program writes information into the
backup and must be validated before becoming the primary operating configuration.
Auto Program will recognize the types of devices connected and will set up different
parameters depending on the devices it finds. The following tables show the settings for
the different device types.
Smoke and thermal detectors
Parameter Description
Label Generic label identifying the detector by loop number and address.
Application If FireSmart detectors are found, the application will not be changed in the
device. Factory default is none.
Sensitivity The sensitivity of the detectors will be left as found. The factory default is
3.00%.
ROR Rate of rise will be off.
Led off LED will be defaulted to ON.
Pre-alarm Pre-alarm will be off.
Verification Verification will be as found in the detector.
Input Usage The input usage will be defaulted to Alarm.
Input Group All detectors will be defaulted to input group 241 (General Alarm).
Network Group This will not be set and will need to be set manually. (Future use)
Relays and
Audible bases
Will be defaulted to auto activation. The relay or audible base will activate
when the device activates.
Monitor Modules, Manual Stations and Conventional Zone modules
Parameter Description
Label Generic label identifying the detector by loop number and address.
Led off LED will be defaulted to ON.
Input Usage Input usage will be defaulted to alarm.
Input Group All inputs will be defaulted to input group 241 (General Alarm).
Network Group This will not be set and will need to be set manually. (Future use)
