MPC-6000 / MPC-7000 / RND-2 PROGRAMMING MANUAL
29
Parameter Description
ROR Rate of rise thermal alarm. This is used for the FireSmart detector and the thermal detector
when the temperature rises at a rate of 15 degrees/minute.
Led off Used to disable the LED on the device so that it does not indicate polling. It will still flash red
for alarm.
Pre-alarm Selected when an early warning of a fire alarm is required. The LED will flash yellow if the
device is in trouble.
Verification This is selected to cause the device to go through the UL defined verification cycle to
eliminate false alarms.
The following table provides a description of the usages that may be set for each device.
Usage Description
Alarm This usage is selected for fire alarm causing devices.
Waterflow Selection for devices connected to Waterflow sensors in sprinkler systems. Generates a non
silenceable alarm event.
Sil. Waterflow If connected to Waterflow sensors in sprinkler systems but the alarm is silenceable.
Trouble Activation of this device will cause a trouble event in the system.
Supervisory Activation of this device will cause a supervisory event in the system.
Panel reset An input with this usage will cause the panel to reset.
Alarm silence An input with this usage will silence the alarm on the panel.
Acknowledge An input with this usage will acknowledge the event on the system.
Test An input with this usage will cause all the logic associated with a device─typically a duct
detector─to activate along with all its associated output zones.
Input Group Each loop input device must belong to one and only one local input group. This is a way of
allowing multiple detectors in one area to be grouped together to provide a common action.
Editing an Input Group Configuration
An input group’s configuration may be edited as follows:
Action Result
1. Select “Edit”.
2. Select “Manual Pgm”.
3. Select “Groups”.
4. Select “Input Groups”.
5. Enter the input group number. The user may now navigate through screens
that allow setting of the various parameters for
a group.
Input Groups
The loop devices must be grouped together (a group of one is possible). There are 240
input groups on the MPC-6000 and MPC-7000 that can be programmed as one of the
following types:
Group Type Description
Fire Typical fire group. Activates selected output zones when an event occurs in the
group.
Counting Used for Counting Zone operation. In this mode of operation, at least the number of
devices given on the Activation Threshold screen must be active before the
corresponding Output Zones will activate.
